Godox ES01 Can Mount More Than Just Lights Thanks to 1/4”-20

Summary

• The Godox ES01 is a motorized suction holder for clean, smooth surfaces
• It has a 1/4”-20 mounting adapter and can mechanically accept compatible lightweight cameras and other accessories, although Godox primarily markets it for lighting
• One ES01 supports loads up to 0.6 kg and the triple ES01 K3 up to 2 kg
• The ES01 weighs approximately 69 grams, measures 68 × 68 × 42 mm and has a 200 mAh battery
• Charging is handled via USB-C in approximately one hour and the official page does not yet list a Greek retail price

The Godox ES01 is a tiny motorized suction holder for smooth surfaces that was designed primarily for lighting, but its 1/4”-20 connection also makes it mechanically compatible with lightweight cameras or other accessories, provided the specified load limits are respected.

Godox has added the ES01 to its Light Stands & Mounting range as a Motorized Suction Holder, a compact system that creates a mounting point on clean, smooth surfaces using powered suction. According to the company, a single ES01 supports loads up to 0.6 kg, while the triple ES01 K3 kit raises that figure to 2 kg.

What makes it particularly interesting is that the ES01 is not mechanically limited to flashes and LEDs. Godox officially presents it as a lighting solution, but it offers a standard 1/4”-20 mounting adapter. This means equipment with a compatible socket — including certain compact or action cameras and other small photography or video accessories — can be attached as long as the complete setup remains within the weight limits. Godox, however, does not describe it on the official product page as a dedicated camera suction mount.

What exactly is the Godox ES01?

The ES01 is an electric suction mount with an integrated vacuum system. Godox says it can be placed on clean, smooth surfaces and uses motorized suction to create a temporary mounting point without requiring a conventional light stand.

The concept is particularly useful in locations where a stand occupies too much space or cannot be positioned in the required spot. Glass and other smooth vertical surfaces can therefore become mounting points for a small light or another lightweight setup.

Can it hold a camera? Mechanically yes, but there is an important distinction

The ES01 offers a 1/4”-20 mounting adapter. The 1/4”-20 thread is the established standard widely used on cameras, action cameras through appropriate adapters, and a large range of photography and video accessories. From a connection standpoint, therefore, a compatible lightweight camera can be mounted to the ES01.

That does not mean Godox presents the ES01 as a dedicated camera mount. In its official material, the company refers to lighting setups and shows compact flashes and LEDs as the main applications. Camera compatibility follows from the standard interface and permitted load rather than an explicit statement from Godox that the ES01 is a camera rig.

On a single ES01, the 0.6 kg limit restricts camera use mainly to very lightweight solutions. A small action camera or compact camera can fall comfortably within that class, while a mirrorless body with a lens can quickly approach or exceed the limit depending on the combination.

Up to 0.6 kg with one ES01 and 2 kg with the K3

Godox specifies a maximum supported load of up to 0.6 kg for a single ES01. For setups requiring greater stability, there is the ES01 K3, which uses three units on a shared three-light connecting bracket and raises the stated load capacity to 2 kg.

The difference matters, particularly when a setup also includes a mount, head, adapter or other hardware. The load figure applies to the total weight the system must support, not just the main camera body or light.

1/4”-20, cold shoe and different mounting options

Godox shows three main connection options: a magnetic cold shoe adapter, a 1/4”-20 cold shoe adapter and a 1/4”-20 mounting adapter. This allows the ES01 to serve different configurations, ranging from small flashes and LEDs to equipment using the standard photography thread.

The standard ES01 package includes the motorized suction cup, a 1/4” cold shoe mount, a hex wrench and a USB-A to USB-C cable. The ES01 K3 includes three ES01 units, the 3-Light Connecting Bracket, one 1/4” cold shoe mount, three charging cables and a hex wrench. Godox also shows the AD-E2 bracket as an optional accessory.

Motorized suction instead of a manual suction cup

The key feature of the ES01 is that the vacuum is generated electrically. According to Godox’s official material, the unit activates motorized vacuum suction with a press, allowing it to attach quickly to a clean and smooth surface.

This reduces the time required for a small rig and makes the ES01 interesting not only for photographic lighting but also for video creators who want to position lightweight equipment in an unusual location without a conventional stand.

Just 69 grams with USB-C charging

The ES01 itself measures 68 × 68 × 42 mm and has a net weight of approximately 69 grams. Its built-in lithium battery is rated at 3.8 V, 200 mAh and 0.76 Wh.

Charging is handled through USB-C at 5 V/0.5 A, and Godox specifies an approximate charging time of one hour. The stated operating temperature range is -10 to 40 degrees Celsius.

Its dimensions and weight are among the product’s main advantages: a single ES01 can remain permanently inside a photography or video bag without the bulk of carrying another small stand.

Price and availability

Godox has already listed the ES01 as a new product on its official website and provides its specifications and manual, but the product page currently does not state an official euro retail price or a specific availability date for the Greek market.

Therefore, any price offered by a local retailer or in another market should be treated as regional pricing rather than an official Greek MSRP from Godox. Find more here.

What we think

The ES01 becomes more interesting when viewed as a general compact mounting tool rather than exclusively as a holder for a small LED. The presence of a 1/4”-20 interface practically opens it up to action cameras, very small compact cameras, monitors, receivers and other lightweight accessories, as long as the connection and total weight are appropriate.

At the same time, there needs to be a clear distinction between “it can be attached” and “it was specifically designed and certified for this purpose.” Godox primarily promotes the ES01 for lighting setups. For an expensive camera, particularly in a vertical or overhead position, a dedicated camera suction rig with corresponding safety provisions remains a different category of product.

Frequently asked questions

Can the Godox ES01 hold a camera?

Yes, mechanically it can accept compatible equipment through its 1/4”-20 mounting adapter. This can include very lightweight compact or action cameras as long as the total load does not exceed the permitted limit. Godox, however, officially presents it mainly as a lighting solution.

How much weight can one ES01 hold?

Godox specifies support for loads up to 0.6 kg for a single unit.

How much weight can the ES01 K3 hold?

The triple K3 version uses three ES01 units and is rated for loads up to 2 kg.

What mounting options does it offer?

The official presentation lists a magnetic cold shoe adapter, a 1/4”-20 cold shoe adapter and a 1/4”-20 mounting adapter, covering different types of lightweight equipment.

How much does it weigh and how does it charge?

The ES01 weighs approximately 69 grams, includes a 200 mAh battery and charges through USB-C in approximately one hour.
